Feature | Technical Description |
1、HW SPEC | |
1.1 Main CPU & SW | |
CPU | MTK6737M |
Android | Android 5.1 OS System |
Language | Multi Language |
1.2 Memory | |
RAM+ROM | 1GB +8GB (up to 32GB) |
SD Card | 32GB |
1.3 LCD | |
LCD | OLED 0.97" |
LCD resolution | 128x64 RGB |
LCD Colors | 16M Color IPS TFT |
1.4 Touch | |
Touch type & size | None |
Glass | Coning generation 3 |
Multi-touch | None |
1.5 Sensor | |
Sensor | 3D Sersor/G-Sersor/ Acceleration Sensor |
1.6 Frequency/Bands | |
Network( GSM, WCDMA, FDD, TDD) | EU band: GSM: B2/B3/B5/B8 WCDMA: B1/B2/B5/B8 TD-SCDMA: B39/B34 FDD-LTE: B1 / B3 / B7 / B8 / B20 / B28 (a&b) TDD-LTE: B38 / B39 / B40 / B41 US band: GSM: B2/B5 WCDMA: B1/B2/B4/B5/B19 FDD-LTE: B1 / B2 / B4 / B5 / B7 / B12 / B13 / B17 / B19 / B28 ( a&b ) |
1.7 Camera | |
Front& Rear Camera | None |
1.8 Wi-Fi | |
IEEE802.11a | Yes (5G) |
IEEE802.11b | Yes(2.4G) |
IEEE802.11g | Yes(2.4G) |
IEEE802.11n | Yes(2.4G&5G) |
WIFI anternna Type | Wi-Fi & BT Coexistence Internal antenna |
1.9 Bluetooth | |
Version | BT V4.0 with BLE / BT2.1 + EDR ( Enhanced Data Rate ) |
Power Level | (Max) Class 2 |
Operation distance | (Max) 10 meter |
2.0 GPS & A-GPS | |
GLONASS Support | None |
GPS Support | Yes |
AGPS Support | Yes |
Antenna Type | Internal antenna |
2.1 Speaker & MIC | |
Output | Φ36mm,2.0W |
SPL | 98dB |
Receiver | 1506 |
MIC Type | Single Pole Mic |
MIC Sensitivity | -42dB±3 |
SIM card | One Micro-SIM card |
Vibrator | None |
2.2 USB | |
USB type | Micro USB |
USB | Micro USB2.0 |
USB | OTG |
Cable length | 1.0m |
2.3 Earjack Interface Type | M6 Connector |
2.4 Indicator LED | 3-colors(Red, Green, Blue) |
3、MD | |
3.1 Size | |
Height ( H * W * D ) | 117*60*29.2mm |
Weight | 182g |
IP code | IP67 |
Drop Test | 1.5m |
3.2 Key buttons | |
keys button | PTT Key / Volume UP / Down Key / Function Key / SOS Key / Power Key |
4、 Battery | |
Battery type | Li-Po |
Battery capacity | 3600 mAh |
Removable battery | Yes |
5, Charge&Date Interfaces | |
5.1 Charging | |
Micro USB ( For Handset ) | Yes |
Battery charging terminal(For Cradle) | Cradle charging |
5.2 Cradle Spec | |
Input voltage | DC 5V/2.0A |
Output voltage | DC 5V/2.0A |
Interface Type | Micro USB |
5.3 Phone Adaptor Spec | |
Input voltage | AC 100-240V, 50 / 60Hz, 0.3A |
Output voltage | DC 5V / 2.0A |
Interface Type | Standard USB |
6、 Environmental Conditions | |
Operating Temperature | -20℃ ~ 60℃ |
Storage Temperature | -30℃ ~ 70℃ |
Humidity | 20% ~ 90% |
ESD | Contact: ±8KV Air: ±12KV |
ROHS 6 Compliant | Yes |
7、 Certification and safety spec | |
Europe | CE |
American | FCC |
